| Cell | Model | 32140 |
|---|---|---|
| Capacity | 10Ah | |
| Rated Voltage | 3.0V | |
| Internal Resistance | ≤20mΩ | |
| Combination Standard | A. Capacity Difference≤1% B. Resistance()=1～3mΩ C. Current-maintaining Ability≥90% D. Voltage2.5～2.8V |
|
| Combination Method | 4S10P | |
| Electrical Characteristics | Nominal Voltage | 12V |
| Nominal Capacity | 100Ah | |
| Energy | >1080Wh | |
| Internal Resistance | ≤10mΩ | |
| Cycle Life | >3000 cycles @1C 70%DOD | |
| Months Self Discharge | <3% | |
| Efficiency of Discharge | 96~99%@1C | |
| Standard Charge | Charge cut-off voltage | 15.6V |
| Charge Current | 20A | |
| Max. Charge Current | 50A | |
| Standard Discharge | Continuous Current | 100A |
| Max. Pulse Current | 1000A | |
| Discharge Cut-off Voltage | 6.0V | |
| CCA | CCA | 500CCA |
| Environmental 环境 |
Charge Temperature | -10 ℃ to 45 ℃ (14F to 113F) @60±25% Relative Humidity |
| Discharge Temperature | -40 ℃ to 60 ℃ (-40F to 140F) @60±25% Relative Humidity |
|
| Storage Temperature | -10 ℃ to 40 ℃ (14F to 104F) @60±25% Relative Humidity |
|
| Water Dust Resistance | IP56 | |
| Mechanical 机械 |
Plastic Case | ABS |
| Dimensions（mm） | 355*175*188mm | |
| Weight(kg) | 13.5KG |
Shipping Details
| Weight | 13.5 kg |
|---|---|
| Dimensions | 355 × 175 × 188 mm |
